Pressure Relief Valve 3 Way Diverter Flow Switch

Quantity:

Pneumatic slide valve is the main flow control transmission equipment for powder, grain and small particles. The worn parts of this gate valve are used of wear-resistant materials, it can operate in a poor environment for a long-term without troubles. Not only automatic water valve flow control, HENT also manufactures gate valves equipped with the electric or manual drive device to control valve’s operation.



High sealing, no leaking



Easy installation, no constrain angle



16Mo3 steel for plate, import from German, no deformation ≤600°C



45# steel for screw, brass for screw assembly, avoid adhesion



Square steel in one side of the gate path, rollers in another side, low f

riction & avoid dust stratification



Difunctional cylinder device, Schneider limit switch ,  smooth, low vibration & noise



SIZE

AXA

B

N×C

D

E

H

400

400×400

400

4×117

516

586

1798

500

500×500

500

4×142

616

686

2108

600

600×600

600

4×167

716

786

2508

700

700×700

700

6×130

850

892

2908

800

800×800

800

8×110

950

992

3308

900

900×900

900

8×123

1050

1092

3708

1000

1000×1000

1000

9×120

1150

1192

4108


Technical Parameters



Size(mm)

400~1000

Capacity(m3/h)

110~750

Pneumatic   Pressure (Mpa)

0.4~0.7

Temperature(°C)

≤550
