Rotary kiln tyre is the main equipment for claiming cement clinker and it can be used widely for cement industry, metallurgy industry, chemical industry, etc.
The rotary kiln is composed of the shell, the supporting device, the supporting device with thrust roller, the driving device, the movable kiln head, the sealing device at kiln tail, the combustion device, etc.
It has the simple structure and reliable operation, at the same the production process of the rotary kiln can be controlled easily.
Through the technical renovations, the rotary kiln claiming system equipment has adopted the advanced hydraulic thrust roller device,and the other national advanced technologies.
Features of Rotary kiln tyre
Rotary kiln tyre is used for calcinating high standard cement in cement factories, but also widely used in metallurgy, construction and chemical industry.
The rotary kiln produced by our factory has strong structure, smooth operation, and high quality products. Besides, we provide our customers with advanced and efficient shaft preheater and five stage cyclone preheater.
Technical parameters of Rotary kiln tyre
Specification | Capacity(t/d) | Kiln obliquity (%) | Bearing quantity | Kiln rotation speed(r/min) | Main driving (r/min) | ||||||
Motor | Reductor | ||||||||||
Main driving | Auxiliary driving | Type | Rated power | Speed adjustment range (r/min) | Rated voltage (v) | Type | Speed ratio | ||||
(KW) | |||||||||||
Φ2.5×40 | 180 | 3.5 | 3 | 0.98-2.94 | 0.036 | YCT315-4B | 45 | 132-1320 | 380 | ZS145-1-I | 49.63 |
Φ2.5×60 | 168 | 3.5 | 4 | 0.516-1.549 | 0.036 | YCT355-4B | 75 | 440-1320 | 380 | ZS165-7-II | 99.96 |
Φ3×48 | 700 | 3.5 | 3 | 0.726-3.63 | 0.1375 | ZSN4-280-091B | 110 | 200-1000 | 440 | ZSY450-35-V | 30.794 |
Φ3×60 | 3.5 | 4 | 0.492-1.476 | 0.034 | YCT355-4B | 75 | 440-1320 | 380 | ZL165-7-I | 99.96 | |
Φ3×100.94 | 450 | 4 | 4 | 0.3-1.503 | 0.275 | ZSN4-250-21B | 90 | 100-1000 | 440 | NZS995-90-VI-L | 90 |
Φ3.2×46 | 1000 | 3.5 | 3 | 0.36-3.57 | 0.108 | ZSN4-280-091B | 160 | 100-1000 | 440 | NZS995-40VIBR | 40 |
Φ3.2×52 | 1200 | 3.5 | 3 | 0.343-2.34 | 0.102 | ZSN4-280-21B | 125 | 100-1000 | 440 | ZSY1110-71BLVI | 71.54 |
Φ3.3×50 | 1300 | 3.5 | 3 | 0.676-3.38 | 0.106 | ZSN4-280-091B | 160 | 200-1000 | 440 | NZS1110-40VI | 40 |
Φ3.3×52 | 1300 | 3.5 | 3 | 0.266-2.66 | 0.0838 | ZSN4-280-11B | 125 | 100-1000 |
